SI-30
Sauermann SI-30 Mini Piston Pump with Remote Detection Float Switch - Condensate Pumps - Air Conditioning Shop - Accessories
One pump for any air conditioner up to 20 kW. Sauermann patented technology inside, specifically designed for discharging condensates from air conditioning systems. Unequalled operating sound level, < 20 dBA, whatever the volume of condensates being discharged.
Ex. VAT
£62.38
Inc. Tax
£74.86
Ex. VAT:
Description
Sauermann SI 30 Mini Piston Pump with Remote Detection Float Switch
One pump for any air conditioner up to 20 kW. Sauermann patented technology inside, specifically designed for discharging condensates from air conditioning systems. Unequalled operating sound level, < 20 dBA, whatever the volume of condensates being discharged.
Applications:
- Wall split systems
- Consoles
- Fan-coil units
- Ceiling suspended
- Ducted units
Benefits:
- Unmatched sound level : < 20 dBA
- Proven reliability
- High performance
- Energy saving
Technical Details:
- Max flow rate: 20 l/h
- Max suction head: 3m
- Max discharge head: 10m
- Electric power: 14 W
- Electric voltage: 230 V~ 50/60 Hz
- Alarm contact: NC 8 A resistive - 250 V
- Detection levels in mm: On: 16, Off: 11, Alarm: 19
- Sound level at 3.3ft: 20 dBA
- Protection: IP20
- Detection: remote
- Thermal protection (overheating): 90 C
- Safety standards: CE
- RoHS and WEEE directives: complies
- Pump Unit Dimensions: 66 mm (l) x 43.5 mm (w) x 60 mm (h)
- Detection Unit Dimensions: 55 mm (l) x 38 mm (w) x 60 mm (h)
Kit contents :
- Piston pump
- Anti-vibration mounting bracket
- Plug in power cable with 2 safety switch wires (1.5 m), 6 tie wraps
- Detection unit SI2958, with cable
- Installation kit: rubber elbow 90 int. dia. 15 x L 60mm, vent tube int. 4 x L 75 mm, mounting rail, adhesive.
More Information
| Product Name | Sauermann SI-30 Mini Piston Pump with Remote Detection Float Switch |
|---|---|
| SKU | SI-30 |
| mpn | SI-30 |
| Brand c2c | Sauermann |
