• Suitable for Pipe Size Diameter: 60mm
• Thickness: 40mm
• Pipe Support Length: 80mm
• **Please Note - Pipe Clamp Not Included - image for Illustration Purposes ONLY**

Suits 60mm Pipe 40mm Thick 80mm Long Rockwool Rocklap Pipe Supports Foil-Faced

**Please Note - Pipe Clamp Not Included - image for Illustration Purposes ONLY**

ROCKLAP Pipe Supports have been designed to minimise the effects of thermal bridging from pipe suspension systems, maintaining the energy
efficiency of pipework operating at temperatures of 0C to 250C.
ROCKLAP Pipe Supports are manufactured with non-combustible stone wool and when combined with ROCKLAP H&V Pipe Sections, form an efficient insulation solution with thermal, fire and acoustic benefits.

Advantages:

• Rockwool Rocklap Pipe Supports Foil Faced
• Non-combustible stone wool
• Minimises thermal bridging
• Foil faced for vapour control
• High point load resistance and effective load bearing capability

Description:

• Multiple sizes avaialble -in a range of thicknesses
• ROCKLAP Pipe Supports are pre-formed sections which are manufactured from high-density ROCKWOOL stone wool
• The ROCKLAP Pipe Supports are precut and finished with a foil facing

Applications:

• ROCKLAP Pipe Supports are suitable for use with both cold/hot steel and copper pipes operating at a temperature range of 0C to 250C. The
• ROCKLAP Pipe Supports are designed for use in pipe supports, hanger brackets and clamps, providing effective load bearing capability and point load resistance.

Technical Details:

• Reaction to fire: Non-combustible stone wool
• Service temperature: Stone wool: 0-250C Aluminium foil: = 80C
• Specific heat: 0.84 KJ/KgK
• Water vapour diffusion resistance:(µ)>10,000
