Little Giant VCMA20S 554471 Automatic Condensate Removal Tank Pump

Automatic Condensate Removal Pump - Little Giant VCMA20s Series
The company that has always been the forerunner in the condensate removal pump design introduces the new generation VCMA Series. Adding features for every installation, with guaranteed serviceability and unmatched reliability, Little Giant Pump Company once again defines the state-of-the-art pump design. Fully Automatic.

Features

• 1/2 gallon leakproof, rustproof, high impact ABS tank
• Three drain holes
• Removable 3/8 barbed check valve
• New generation float arm for enhanced reliability
• Thermal overload protection
• Optional safety switch
• Suitable for High-Efficiency, Gas-Furnace Condensate
• ABS plastic motor and tank cover, and volute
• Polypropylene Impeller
• Stainless steel shaft
• Snap-action switch
• 6' power cord with 3-pronged plug
• Easy installation
• UL & CSA listed
• Features - Fully automatic: Start, Stop, Safety Switch
• Maximum head: 4,3m (14.1 ft.)
• Maximum flow: 294 l/h
• Operating point: 4,0m (13,1 ft.) 70 l/h
• Check valve outlet: 9,5mm (3/8) For 9,5mm (3/8) I.D. tubing
• Tank volume: 1,9 l (1/2 gallon)
• Maximum liquid temperature: 50C
• Suitable for condensate with 2,8 pH
• Thermally protected motor
• IP20
• Weight 2,4Kg (20ST = 2,8Kg.)
• 1,8m electric cable
• Options: 6m tubing (VCMA-20ST) and/or CEE electric plug
