22mm Diameter 20mm Wall Kingspan Kooltherm Foil-Faced Phenolic Pipe Insulation

Kingspan Kooltherm premium performance pipe insulation is one of the thinnest and most efficient products available for the insulation of pipework in building services / HVAC applications. It is available in a range of thicknesses to suit different performance specifications and may be used on mild steel, stainless steel, carbon steel, copper and plastic pipework.

Kingspan Kooltherm has Excellent Thermal Performance Properties:

With a 25 year aged thermal conductivity as low as 0.025 W/mK (at 10°C mean), Kooltherm Pipe Insulation is one of the most thermally efficient insulation materials commonly used. A low thermal conductivity allows specified thermal performance standards to be achieved with thinner insulation. The thermal performance of Kooltherm Pipe Insulation derives mainly from its closed cell properties. Its closed cell structure has been optimised to resist heat transfer. The closed cells have a small solid to void volume ratio, are small and uniform in size, and their construction very fine with extremely thin walls and minimum point contacts (struts).They are filled with a thermally efficient CFC / HCFC-free blowing agent that has low Ozone Depletion Potential (ODP) and low Global Warming Potential (GWP).

As a result of its closed cell, fibre free structure, Kooltherm Pipe Insulation is unaffected by air infiltration – problems that can be experienced with mineral fibre and which can reduce thermal performance.

Fire Performance:

Kooltherm Pipe Insulation has excellent fire and smoke performance. Please visit https://www.kingspan.com/gb/en/products/hvac-insulation/pipe-insulation/kooltherm-pipe-insulation/ for further information

Moisture Resistance:

Kooltherm Pipe Insulation has a closed cell structure. The risk of moisture absorption into the insulation is effectively eliminated as the factory applied facing to Kooltherm Pipe Insulation products and systems provides a high performance vapour barrier jacket.
